Sammlung Architektonischer Entwürfe plates 37-42



37. Perspective of the new museum as seen from a point between the Zeughaus and the new Schlossbrücke -- Altes Museum, Berlin, 1822-1830. detail


38. Three floor plans; the lower story, the first and second story -- Altes Museum, Berlin, 1822-1830. detail


39. South elevation, main facade -- Altes Museum, Berlin, 1822-1830. detail



40. Transverse section; Ionic order of colonnade with entablature -- Altes Museum, Berlin, 1822-1830. detail


41. North elevation; view of the main stair and details -- Altes Museum, Berlin, 1822-1830. detail


42. Map of the city indicationg the changes made because of the museum; interior columns details -- Altes Museum, Berlin, 1822-1830. detail

««««

»»»»
