Plan of the church, Chiesa Nuova, erected at Assisi, by Philip III, king of Spain, over the remains of the paternal house of St. Francis, indicated by a darker tint at A and B.
Plan on a larger scale of the chamber A in which St. Francis was born in 1182.
Transverse section of the same chamber; the original roof is a semicircle, the restoration a pointed arch.
